Steel Frame & Purlin Machine
Place of Origin:
Purlin Roll Forming Machine
40Cr Diameter 80mm
Cutting blade material:
Cr12Mov Mold Steel
Product Certification Verified
Valid from 2017-03-29 until 2022-03-28
10 Set/Sets per Month
Packaging & Delivery
Light gauge steel frame roll forming machine
The LG series is an intelligent light steel villa construction keel device that can be independently developed and produced by Dahe Zhongbang Intelligent Technology. It can realize CNC machining of various components such as wall, floor and even stairs. The operation process can directly import design data or directly input required parameters. The model change only needs to input the changed specification size on the console and click on the change type. The entire device is then fully automatically moved to the desired position without manual intervention. High flexibility and intelligent production are a major feature of LG. Under the background of the new era, light steel buildings are developing at a high speed in various application fields such as high-rise, heavy-light combination, and a highly flexible intelligent light steel processing equipment is your choice for the future.
Spindle double holding brake
Fixed Storage table
1. The design system includes the following software modules:
VERTEX BD Pro (VXB-114): The standard package contains: – Architectural Design Full architectural drawings, 3D browser with furniture & accessories.
Tools for creating presentable models (e.g. Fascia, Soffits, Window & Door Trims, Guttering...) – 3D Modelling and 2D Drafting – DWG, DXF, 3DS, IGES and SAT -interfaces – Archiving tools – OpenGL-rendering – Material database – Wall, Floor and Roof panels and roof trusses.Automatic panel drawings/Automatic truss structure drawings/Automatic joist & rafter layout drawings – Bill of materials, Cutting lists – First year support and maintenance.
2. The Decoiler
De-coiler Type: Auto Hydraulic de-coiler Weight capacity: 3.0T
All punching dies are made from Cr12Mov. Holes parameter is able to set by computer; Hole Type can be customized.
4. Rolling Forming System
Main motor type: servo motor Speed of forming: 48m/min Roller: 12 groups of rollers. Shaft & Frame: Shafts of rollers are tooled by grinding machine for two times to ensure the precision of final product. The frame is designed as strong as required to bear the whole rollers and shafts. Material of main shaft : 40Cr. Machine frame Material of frame: A3# steel
5. Hydraulic Cutting
Cutting material: Cr12MoV Online printer: Online inkjet printing system. Marks and Item Number are available to be printed on the flange side for easy assembling pieces to pieces.
Out-let Table: 4 meters Product support frame C stud to the stack platform. Safety Guard: Safety Guard covers the whole machine to ensure worker's safe.
Width: 89/140/300 mm (adjustable)
Height: 41 mm
Lip: 7-12 mm
Packing & Delivery
1.More than 10 spare parts inventory, to help you in the shortest time to the most reasonable price received needs accessories. Whether you are within the warranty period and the warranty period, we are always providing support for your production.
2.Maintenance and support: In your device before the factory sales service department to establish the archives service for you, every service response time, speed and quality are truthful to record and track, constantly upgrading equipment experience to optimize the production. Is the purchase of equipment for customers, if models have upgrade mate. You can also choose to upgrade service, only a small number of investment you can make your brand new. We believe that only the specificity, focus on the professional technology to achieve the commitment to customers.
3.Operator training: "Management starts with training, training", and improving the training is the premise of achieving first-class production, we provide the following four ways in the long time when customers need to choose: 1) customers responding to commissioning personnel training (purchase offer);
2) the customer on-site invited training (need to choose); 3) customer on-site 7 days to accompany production (need to choose); 4) we on-site commissioning and production training (need to choose when);
4.Technical support: Any problems resulting from the process of your production can be easily handled by our sales service hotline and we have a perfect sales service process to ensure that your problem is solved in the shortest time.. Our long-term commitment to researching and manufacturing of CZ type steel equipment, the long-term practical experience and customer production experiences are imposed on statistics and analysis, and in our technology website for customers to share. Focus, sharing is the attitude of our service!
