High Speed Light Gauge Keel Framing Cold Roll Forming machine For Villa

FOB Reference Price:Get Latest Price
$90,000.00 - $115,000.00 / Sets | 1 Set/Sets (Min. Order)
Model Number:
LG-10
Report Suspicious Activity
Overview
Quick Details
Warranty:
1 Year
Power(W):
35M/min
Certification:
ISO CE SGS
After-sales Service Provided:
Online support, Field installation, commissioning and training, Field maintenance and repair service, Video technical support
Type:
Steel Frame & Purlin Machine
Applicable Industries:
Building Material Shops, Manufacturing Plant, Home Use, Construction works
Condition:
New
Work Pressure:
22KW
Production Capacity:
35M/min
Place of Origin:
Fujian, China
Brand Name:
DAHE, DAHE
Voltage:
380V
Dimension(L*W*H):
5.4m*0.98m*1.5m
Weight:
3500KGS
Product name:
Purlin Roll Forming Machine
Control system:
PLC(imported Brand)
Color:
Blue
Shaft material:
40Cr Diameter 80mm
Roller material:
GCr15
Usage:
Villa
Cutting blade material:
Cr12Mov Mold Steel
Product Certification Verified
CE Certified.
Valid from 2017-03-29 until 2022-03-28
Supply Ability
Supply Ability:
10 Set/Sets per Month
Packaging & Delivery
Port
XIAMEN
Picture Example:
package-img
Product Description


 Light gauge steel frame roll forming machine


The LG series is an intelligent light steel villa construction keel device that can be independently developed and produced by Dahe Zhongbang Intelligent Technology. It can realize CNC machining of various components such as wall, floor and even stairs. The operation process can directly import design data or directly input required parameters. The model change only needs to input the changed specification size on the console and click on the change type. The entire device is then fully automatically moved to the desired position without manual intervention. High flexibility and intelligent production are a major feature of LG. Under the background of the new era, light steel buildings are developing at a high speed in various application fields such as high-rise, heavy-light combination, and a highly flexible intelligent light steel processing equipment is your choice for the future.


Main Device
   Device Configuration
weight(kg)

Machine

5000×1100×1300(mm)
punching configuration
pre-punching
3000

Decoiler(Automatic)

1400×1150×1280(mm)
bearing
3  tons
770
Tension mode
Hydraulic tension
Spindle double holding brake
Self-driven feeding

Support table

4000×1120×1084(mm)
support length
6  meters
200
support method
Fixed
Storage table
                                                                Main Components
1. The design system includes the following software modules:
VERTEX BD Pro (VXB-114): The standard package contains: – Architectural Design Full architectural drawings, 3D browser with furniture & accessories.

Tools for creating presentable models (e.g. Fascia, Soffits, Window & Door Trims, Guttering...) – 3D Modelling and 2D Drafting – DWG, DXF, 3DS, IGES and SAT -interfaces – Archiving tools – OpenGL-rendering – Material database – Wall, Floor and Roof panels and roof trusses.Automatic panel drawings/Automatic truss structure drawings/Automatic joist & rafter layout drawings – Bill of materials, Cutting lists – First year support and maintenance.

2. The Decoiler
De-coiler Type: Auto Hydraulic de-coiler
Weight capacity: 3.0T

3. Punching
All punching dies are made from Cr12Mov.
Holes parameter is able to set by computer; Hole Type can be customized.

4. Rolling Forming System
Main motor type: servo motor
Speed of forming: 48m/min
Roller: 12 groups of rollers.
Shaft & Frame: Shafts of rollers are tooled by grinding machine for two times to ensure the precision of final product.
The frame is designed as strong as required to bear the whole rollers and shafts.
Material of main shaft : 40Cr.
Machine frame Material of frame: A3# steel

5. Hydraulic Cutting
Cutting material: Cr12MoV
Online printer: Online inkjet printing system. Marks and Item Number are available to be printed on the flange side for easy assembling pieces to pieces.
Out-let Table: 4 meters Product support frame C stud to the stack platform.
Safety Guard: Safety Guard covers the whole machine to ensure worker's safe.

                                                           Specifications
Width: 89/140/300 mm  (adjustable)
Height: 41 mm
Lip: 7-12 mm
Thick:0.75-1.2  mm
Packing & Delivery
Our company&factory
Our Customers
Our Exhibition
Our Service

1.More than 10 spare parts inventory, to help you in the shortest time to the most reasonable price received needs accessories. Whether you are within the warranty period and the warranty period, we are always providing support for your production.


2.Maintenance and support: In your device before the factory sales service department to establish the archives service for you, every service response time, speed and quality are truthful to record and track, constantly upgrading equipment experience to optimize the production. Is the purchase of equipment for customers, if models have upgrade mate. You can also choose to upgrade service, only a small number of investment you can make your brand new. We believe that only the specificity, focus on the professional technology to achieve the commitment to customers.

3.Operator training: "Management starts with training, training", and improving the training is the premise of achieving first-class production, we provide the following four ways in the long time when customers need to choose:
1) customers responding to commissioning personnel training (purchase offer);
2) the customer on-site invited training (need to choose);
3) customer on-site 7 days to accompany production (need to choose);
4) we on-site commissioning and production training (need to choose when);

4.Technical support: Any problems resulting from the process of your production can be easily handled by our sales service hotline and we have a perfect sales service process to ensure that your problem is solved in the shortest time..
Our long-term commitment to researching and manufacturing of CZ type steel equipment, the long-term practical experience and customer production experiences are imposed on statistics and analysis, and in our technology website for customers to share. Focus, sharing is the attitude of our service!
